使用 swoole 加速 Laravel5.6 Restful API 接口

点赞

5

1. 创建自定义artisan命令
   php artisan make:command SwooleServer //默认在app/Console/Commans目录下创建SwooleServer.php文件。可借鉴我的上一遍文章Laravel 5.6 中优雅的管理 swoole 进程代码如下：

       <?php

       namespace App\Console\Commands;
       use Illuminate\Console\Command;
       use Illuminate\Support\Facades\App;

       class SwooleServer extends Command
       {
           //swoole http server instance
           private $server;

           //进程ID
           private $pid_file;

           //日志文件
           private $log_file;

           /**
            * The name and signature of the console command.
            *
            * @var string
            */
           protected $signature = 'swoole {action}';

           /**
            * The console command description.
            *
            * @var string
            */
           protected $description = 'start or stop the swoole http server';

           /**
            * Create a new command instance.
            *
            * @return void
            */
           public function __construct()
           {
               parent::__construct();
               //指定主进程PID存储文件
               $this->pid_file = __DIR__ . '/../../../storage/swoole_server.pid';
               //日志文件存储
               $this->log_file = __DIR__ . '/../../../storage/logs/' . date('Ymd') . '_swoole_server.log';
               if (!is_file($this->log_file)) {
                   $resource = fopen($this->log_file, "w");
                   fclose($resource);
               }
           }

           /**
            * Execute the console command.
            *
            * @return mixed
            */
           public function handle()
           {
               //获取传递的操作
               $arg = $this->argument('action');

               switch ($arg) {
                   case 'start':
                       //检测进程是否已开启
                       $pid = $this->getPid();
                       if ($pid && \Swoole\Process::kill($pid, 0)) {
                           $this->error("\r\nswoole http server process already exist!\r\n");
                           exit;
                       }

                       $this->server = new \Swoole\Http\Server("0.0.0.0", 9501);
                       $this->server->set([
                           'worker_num' => 8,
                           'daemonize' => 1,
                           'max_request' => 1000,
                           'dispatch_mode' => 2,
                           'pid_file' => $this->pid_file,
                           'log_file' => $this->log_file,
                           'log_level' => 3, //日志等级 notice
                       ]);

                       //绑定操作类回调函数
                       $app = App::make('App\Handles\SwooleServerHandle');

                       $this->server->on('workerstart', array($app, 'onWorkerStart'));
                       $this->server->on('request', array($app, 'onRequest'));

                       $this->info("\r\nswoole http server process created successful!\r\n");

                       $this->server->start();
                       break;

                   case 'stop':
                       if (!$pid = $this->getPid()) {
                           $this->error("\r\nswoole http server process not started!\r\n");
                           exit;
                       }
                       if (\Swoole\Process::kill((int)$pid)) {
                           $this->info("\r\nswoole http server process close successful!\r\n");
                           exit;
                       }
                       $this->info("\r\nswoole http server process close failed!\r\n");
                       break;

                   default:
                       $this->error("\r\noperation method does not exist!\r\n");
               }

           }

           //获取pid
           private function getPid()
           {
               return file_exists($this->pid_file) ? file_get_contents($this->pid_file) : false;
           }
       }

2. 编写操作类SwooleServerHandle

    <?php
   /**
    * Created by PhpStorm.
    * User: kite
    */

   namespace App\Handles;

   class SwooleServerHandle
   {
       //header Server 全局变量的映射关系
       private static $headerServerMapping = [
           'x-real-ip'       => 'REMOTE_ADDR',
           'x-real-port'     => 'REMOTE_PORT',
           'server-protocol' => 'SERVER_PROTOCOL',
           'server-name'     => 'SERVER_NAME',
           'server-addr'     => 'SERVER_ADDR',
           'server-port'     => 'SERVER_PORT',
           'scheme'          => 'REQUEST_SCHEME',
       ];

       public function onWorkerStart($serv,$worker_id)
       {
           require __DIR__.'/../../vendor/autoload.php';
           require_once __DIR__.'/../../bootstrap/app.php';
       }

       public function onRequest($request,$response)
       {
           //server信息
           $_SERVER =[];
           if (isset($request->server)) {
               foreach ($request->server as $k => $v) {
                   $_SERVER[strtoupper($k)] = $v;
               }
           }

           //header头信息
           if (isset($request->header)) {
               foreach ($request->header as $key => $value) {
                   if (isset(self::$headerServerMapping[$key])) {
                       $_SERVER[self::$headerServerMapping[$key]] = $value;
                   } else {
                       $key = str_replace('-', '_', $key);
                       $_SERVER[strtoupper('http_' . $key)] = $value;
                   }
               }
           }
           //是否开启https
           if (isset($_SERVER['REQUEST_SCHEME']) && $_SERVER['REQUEST_SCHEME'] === 'https') {
               $_SERVER['HTTPS'] = 'on';
           }
           //request uri
           if (strpos($_SERVER['REQUEST_URI'], '?') === false && isset($_SERVER['QUERY_STRING']) && strlen($_SERVER['QUERY_STRING']) > 0
           ) {
               $_SERVER['REQUEST_URI'] .= '?' . $_SERVER['QUERY_STRING'];
           }

           //全局的
           if (!isset($_SERVER['argv'])) {
               $_SERVER['argv'] = isset($GLOBALS['argv']) ? $GLOBALS['argv'] : [];
               $_SERVER['argc'] = isset($GLOBALS['argc']) ? $GLOBALS['argc'] : 0;
           }

           //get信息
           $_GET = [];
           if (isset($request->get)) {
               foreach ($request->get as $k => $v) {
                   $_GET[$k] = $v;
               }
           }

           //post信息
           $_POST = [];
           if (isset($request->post)) {
               foreach ($request->post as $k => $v) {
                   $_POST[$k] = $v;
               }
           }

           //文件请求
           $_FILES =[];
           if (isset($request->files)) {
               foreach ($request->files as $k => $v) {
                   $_FILES[$k] = $v;
               }
           }
           //cookie
           $_COOKIE=[];
           if (isset($request->cookie)) {
               foreach ($request->cookie as $k => $v) {
                   $_COOKIE[$k] = $v;
               }
           }

           ob_start();//启用缓存区
           \Illuminate\Http\Request::enableHttpMethodParameterOverride();
           $kernel = app()->make(\Illuminate\Contracts\Http\Kernel::class);
           $laravelResponse = $kernel->handle(
               //Create an Illuminate request from a Symfony instance.
               $request =  \Illuminate\Http\Request::createFromBase(new \Symfony\Component\HttpFoundation\Request($_GET, $_POST, [], $_COOKIE, $_FILES, $_SERVER, $request->rawContent()))
           );

           $laravelResponse->send();
           $kernel->terminate($request, $laravelResponse);
           $res = ob_get_contents();//获取缓存区的内容
           ob_end_clean();//清除缓存区
           //输出缓存区域的内容
           $response->end($res);
       }
   }

3.使用php artisan swoole start即可开启服务，在nginx配置代理即可加速你的Restful api接口.
4.在centos7 单核 2G内存下的测试结果如下：
未使用swoole的吞吐量只有2.44

使用了swoole的吞吐量提升到了56.19且加大并发数吞吐量都可以维持一个水平
